T2M-IP has now made available their partners 5GNR R15* compliant L1/2/3 Phy and SW Stack to enable customers to develop 5GNR network products and services.

Supported implementations include:

  • Enhanced Mobile Broadband (eMBB).
  • Ultra-Reliable and Low Latency Communications (URLLC)
  • Massive Machine-Type Communications (mMTC)

A complete reference design is available for 5GNR RU and gNodeB (the component in LTE Radio Access Network (RAN)) on an FPGA (field-programmable gate array) / SDR (software defined radio) platform. The 5GNR gNodeB reference design supports bandwidths up to 100 MHz for the FR1 with both TDD (Test-Driven Development) and FDD (Feature-Driven Development) 4T4R (4T4R is a transmit and receive mode for base stations with four transmit and four receive antennas) configuration supported in the 5G spectrum. The solution employs combination of FPGA and high-end embedded processor for realizing the gNodeB (a 5G Base Station uses New Radio (NR) technology and is referred to as a gNodeB) that operates in both SA and NSA (Stand-Alone / Non-Stand Alone) mode .

The solution is completely modular with the clear interface between various RAN functional modular splits. The 5G solution is optimized to handle very high data rates with support for eMBB (enhanced Mobile Broadband) and is being extended to support a very large number of users’ with mMTC (massive Machine Type Communications).

The RU (rack unit) reference design supports FR1 with 4T4R configuration. The RU is compliant to ORAN 7.2x interface with support for Category A. The RU supports 4G and 5G technology thus providing the option for operators to upgrade the radios in the network in a phased manner.

The reference design includes high power PA, LNA for popular FR1 bands. Interworking with test and measurement equipment and multiple DU vendors are in progress. The RU solution has a roadmap for supporting Massive MIMO (Multiple In, Multiple Out) is a new radio access technology (RAT) developed by 3GPP for the 5G (fifth generation) mobile network. It was designed to be the global standard for the air interface of 5G networks.) configuration with a 64T64R antenna configuration.

The 5G UE reference design includes platform independent Phy & SW stacks for L1, and L2/L3. The design can be adapted to run on SoCs (System on a Chip) with integrated DSP (Digital Signal Processing) (Ceva/Tensilica) and embedded processor cores (ARM/RISC-V). Software stacks can be demonstrated running in isolation on an Intel x86 based Host computer. The UE has a support for USM, soft SIM and Sim free operation and OS and HW abstraction for easy portability as per the customer’s requirement.

There is a roadmap to support Release 16 and FR2 mode for all the 5G NR solutions. Other IPs associated with this technology includes SDR RF, LTE/4G UE/e-nodeB and NB-IoT IPs.

  • SDR RF IP: The four Generations of SDR RF IP family are ultra-low-power radio solutions optimized from IoT and M2M to 5G applications. They integrate all the necessary RF/analog/mixed-signal functions to support radio functions for most standards operating from 100MHz -2.6GHz and beyond as per customer’s requirements.
  • 4G/ LTE UE/e-nodeB: 3GPP compliant LTE/4G Release 10 with complete system solution on the UE and e-nodeB, readily available for deployment, offers lower cost of ownership and accelerated time to market. Using this Reference Design, OEMs can build LTE UEs for different form factors like a Handset, Manpack or Outdoor type. The used gets extreme flexibility for Tactical and Private networks where both centralized and distributed mode of deployment is supported on same HW
  • NB-IoT IPs: 3GPP compliant NB-IoT Release 14 with complete Protocol Stack SW, Digital and PHY, both on the UE and the e-nodeB side is available for commercial deployment to the customers. The NB-IoT IPs are highly configurable and are designed to support Low memory and low power footprints enabling customers to integrate with their custom target platform.

T2M-IP is a global, independent, semiconductor technology provider, supplying complex IP, software, KGD and disruptive technologies that enable the accelerated production of cellular, IoT, wireless, consumer and automotive SoCs.

*5G NR (New Radio) is a new radio access technology (RAT) developed by 3GPP for the 5G (fifth generation) mobile network and was designed to be the global standard for the air interface of 5G networks.
